1. Flow rate: 100~10.000Nm3/H
2. Working pressure: 0.1~70MPa
3. Medium: Liquid oxygen, liquid nitrogen, liquid argon, liquid CO2, etc...
Note: Multiple combinations can be used for larger flows.
Notes for proposal request:
- Flow rate
- Media gas
- Inlet pressure
- Outlet pressure
Product characteristics:
1. Easy installation and maintenance
2. Special aluminum heat exchange, high efficiency, lightweight design, long service life
3. Special super large diameter special aluminum heat exchange tube, extremely fast defrosting speed, effective inner fin structure, greatly improving the heat exchange tube
4. Advanced high-pressure pipe composite technology makes the pressure pipe fully contact with the heat exchange pipe to ensure the heat exchange efficiency
Some low quality air heated vaporizers have many disadvantages:
1. The aluminum is low quality with low intensity.
2. Less fins than good one. And the fin is very thin, so that will decrease the heat exchange effect. When it is freezing, the fin will be bended by the ice.
3. Welding gap is not sealed well, which cause gas leakage.
4. The thickness is not even, causing working intensity and heat exchange.
5. The stainless steel pipe is not thick enough and welding craft is not so good.
6. Non- destructive test isn’t done or not enough, which will make gas leakage problem.
7. After producing, we use Nitrogen gas to test leakage, and use water pressure to test intensity. Some factories cancel this process in order to decrease the cost. Therefore, their customer is the victim.
