Introduction
Advanced technologies are embodied in our piston compressor. It is a reciprocating compressor with a piston in a reciprocating motion. The cylinder, valve and piston form a volume. By changing the volume, the piston compressor completes the compression process. The whole process can be divided into expansion, suction, compression and exhaustion steps. The machine is a common industrial compressor.
We can supply the following piston compressors:
1. volume flow rate: 2-600m3/min
2. discharge pressure: 0.1-30.0MPa
3. motor power: 11-2000KW
4. piston force: 1-25T
Cryogenic Liquefaction Complement Compressor (Feed gas: air or LNG)
1. volume flow rate: 1-600m3/min
2. discharge pressure: 0.10-6.00MPa
3. motor power: 11-3000KW
4. piston force: 1.0-50T
N2 Compressor
1. volume flow rate: 2-600m3/min
2. discharge pressure: 0.10-6.00MPa
3. motor power: 37-2000KW
4. piston force: 1.0-25T
O2 Compressor
1. volume flow rate: 2-600m3/min
2. discharge pressure: 0.10-6.00MPa
3. motor power: 37-2000KW
4. piston force: 1.0-25T
Acetylene Compressor
1. volume flow rate: 20-6000Nm3/h
2. discharge pressure: 0.1-3.0MPa
3. motor power: 3-650KW
4. piston force: 1-5T
CO2 Compressor
1. volume flow rate: 2-600m3/min
2. discharge pressure: 0.1-9.0MPa
3. motor power: 11-2000KW
4. piston force: 1-25T
Purchasing Guide
Please advise the following when sending an enquiry:
1. medium
2. volume flow rate
3. working pressure
